PC-7 Airplane Smoking System

Pilatus PC-7

Swiss FOCA AnnexII aircraft

Generate smoke in your aerobatic flight

The iconic Pilatus PC-7 MKII was developed from the preceding Pilatus P-3 with the introduction of a turboprop engine, a bubble canopy and a new one-piece wing among other developments. Training operations represent its main field of adoption worldwide and its aerobatic capabilities made it a true icon in aviation history!

Nowadays it is employed also by several private pilots passionate for aviation and airshows. Swiss Helicopter Engineering, together with our partner AeLo Maintenance, developed a fully certified solution for the installation of the American made smoke generation system of Smoking Airplanes inside the PC-7 battery compartment.

Battery compartment installation

Traditional installations take advantage of baggage compartment sacrifying most of the available space. We don't.

5.5 Gal/21 Liters of oil capacity

You can rely on a big capacity oil tank to extend at maximum your smoke generation capability.

7 minutes of smoke range

Your smoke generation will last for a 7 minutes of RUN TIME!

Smoking Airplanes VCAS SA 201 System

You can rely on a widely employed system in many other aircraft types!

BATTERY COMPARTMENT

You don't have to sacrifice space in you baggage compartment

To accomodate the installation of your new smoke generator, we've designed and certified a minor structural modification for your safety in flight. You just have to enjoy that!

Your baggage compartment will not be modified.

PC7 battery Compartment with Smoke system

Cockpit

Always under control

Thanks to the indicator light in the cockpit, you will always be able to monitor activity during your flight. Activating and deactivating the system is child's play.

Safety First

Careful design and stress testing

We designed the system carefully, down to the last detail. Stress-test simulations were also carried out to ensure maximum safety in all conditions.

PC-7 Smoke system

We have tested it in numerous aerobatic figures, to make sure it works in all conditions. Watch it in action.

7min

Your smoke generation will last for a 7 mnutes of RUN TIME!

5.5 Gal oil capacity

You can rely on a big capacity oil tank to extend at maximum your smoke generation capability.

Download the flyer

We have certified the smoke system,
and it is ready to be installed in your Pilatus PC-7.

Download

Your solution at a glance

Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor invidunt ut labore et dolore magna aliquyam erat, sed diam voluptua. Lorem ipsum dolor sit amet, consetetur sadipscing elitr. Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor invidunt ut labore et dolore magna aliquyam erat, sed diam voluptua.

Swiss FOCA approved

5.5 GAL/21 LITERS capacity

12v pump (& 24v to 12v converter)

NO changes in the baggage compartment

Easy activation from cockpit

Pump flow: 1.8 +/- GPM

Rated for 18g

Engineered for continuous inverted flight

AVAILABILITY

The smoke system is ready for your Pilatus PC-7 installation

We have certified the smoke system, and it is ready to be installed in your Pilatus PC-7.
If you are planning to develop such a solution for a different aircraft type, do not hesitate to contact us and we will provide a customized certification plan.

Pilatus PC-7

Ask for a quotation! Approval can be validated to other civil aviation authority and extended to your aircraft S/N on request.

Ready to be installed

Swiss FOCA approved

5.5 Gal of capacity

Different type?

Let's study together! We will find a solution together.

Describe your needs

Send us your aircraft records

Receive a certification plan!

Let's study together!

Would you like to buy this product or do you have any questions?

Contact us without obligation. We are here to answer your questions, adapt the offer or customise the product to your needs.
